1.5 Mil Aluminum Foil Tape
Series 230-800

1.5 Mil Aluminum Foil Tape









PRODUCT:
East Coast Shielding 230-800 is a general purpose 1.5 mil Aluminum Foil Tape with liner.

PRINCIPLE USES:
East Coast Shielding 230-800 dead-soft aluminum foil tape is a general purpose foil used on non-critical applications such as sealing out dust and moisture, masking, and duct sealing.

FEATURES/BENEFITS:
East Coast Shielding 230-800 aluminum foil is coated with an extremely aggressive acrylic adhesive providing service temperatures from 0 degrees F to 150 degrees F (-18 degrees C to 66 degrees C) and application temperatures from 10 degrees F to 120 degrees F (-12 degrees C to 49 degrees C). Due to the dead-soft nature of the foil, it can be used on irregular and curved surfaces.

TECHNICAL DATA

TEST METHOD

VALUE
  • Substrate
  • N/A
  • Dead-Soft Aluminum
  • Adhesive
  • N/A
  • Acrylic (clear)
  • Foil Thickness
  • PSTC-33 ASTM D3652
  • 1.5 mils (0.04mm)
  • Tape Thickness without Liner
  • PSTC-33 ASTM D3652
  • 3.0 mils (0.08mm)
  • Color
  • Visual
  • Silver Metallic
  • Adhesion to Steel
  • PSTC- 1 ASTM D3330
  • 45 oz/inch (50N/100mm)
  • Tensile Strength
  • PSTC-31 ASTM D3759
  • 25 lbs/inch (438N/100mm)
  • Elongation
  • PSTC-31 ASTM D3759
  • 5%
  • Release Liner
  • PSTC-33 ASTM D3652
  • 4.0 mils (0.10mm)
  • Permeance
  • ASTME-96
  • 0.0 perms
  • Flammability
  • UL510, SECTION 4File #E130121
  • Recognized Component


SURFACE PREPARATION: The surface to which the tape is applied should be dry, clean, and free of contaminants.

STORAGE CONDITIONS: Tape should be stored in a dry area at temperatures of 60 degrees F (16 degrees C) to 80 degrees F (26 degrees C).

NOTE: All physical properties listed above have been obtained from random laboratory testing and should not be used for the purpose of writing specifications. THE PRODUCT SHOULD BE TESTED TO DETERMINE THE SUITABILITY FOR ITS INTENDED USE.



Acrobat Reader Download PDF of FULL product specifications... Click Here
